A1
|
37.5 mm
|
|
JB
|
100 mm
|
|
b
|
45 mm
|
width rail
|
Tolb
|
-0.005 mm
|
Upper tolerance
|
Tolb
|
-0.035 mm
|
Lower tolerance
|
A2
|
10 mm
|
|
L1
|
136.6 mm
|
|
JL
|
80 mm
|
|
JLZ
|
60 mm
|
|
jL
|
52.5 mm
|
|
aLmin
|
20 mm
|
1
|
aLmax
|
41 mm
|
1
|
aRmin
|
20 mm
|
Distance 1
|
aRmax
|
41 mm
|
1
|
H1
|
8.5 mm
|
|
H4
|
26 mm
|
|
H5
|
8 mm
|
|
T5
|
15 mm
|
|
T6
|
13.2 mm
|
|
h
|
38 mm
|
|
h1
|
19.5 mm
|
|
Tolh1
|
0.5 mm
|
Upper tolerance
|
Tolh1
|
-0.5 mm
|
Lower tolerance
|
G2
|
M12
|
|
G2MA
|
83 Nm
|
maximum tightening torque²
|
K1
|
M12
|
|
K1MA
|
140 Nm
|
maximum tightening torque
|
K3
|
M10
|
|
K3MA
|
83 Nm
|
maximum tightening torque²
|
K6
|
M10
|
|
K6MA
|
48 Nm
|
maximum tightening torque²
|
d1
|
10.6 mm
|
|
D2
|
10.6 mm
|
|
N2max
|
6 mm
|
3
|
JL5
|
31.9 mm
|
4
|
A3
|
6.6 mm
|
|
GS
|
M4x4
|
|
O
|
10x1,5
|
O-Ring DIN 3771
|
≈m
|
0
|
kg text.product.weight
|
